V-ZUG 76cm Combi Induction Cooktop with Downdraft Extraction 3109600002
V-ZUG 76cm Combi Induction Cooktop with Downdraft Extraction 3109600002
Model
3109600002
Condition Description
Ex display.
Ducting is not included and ordered separately.
Needs to be hardwired.
Missing parts
Installation clips (if not installed).
Brand
Standard Warranty
5 years
Up to 12 months interest free with Zip Money
Specifications & Manuals
Key Specifications
| Cooktop Type | Ceramic |
|---|---|
| Rangehood Type | Cooktop with Integrated Extractor |
| Cooktop Fuel Type | Electric |
| Model Number | 3109600002 |
| Fuel Type | Electric |
| Weight (kg) | 19.82 kg |
| Depth (mm) | 501 mm |
| Height (mm) | 206 mm |
| Width (mm) | 761 mm |
| Power (W) | 7400 W |
| Accessories included | 1 x Stainless Steel Mesh Filter |
| Cooktop Material | Ceramic Glass |
| Finish Colour | Black |
| Notes | **This model requires hardwiring by a qualified electrician.**
|
| Cookware compatibilty | Please note that induction cooktops are only compatible with cookware made from magnetic material. |
| Finish Colour Description | Black Ceramic Glass Finish. |
| Installation Note | Able to Built into your Benchtop Proud or Flush Mounted |
Burners
| Number of cooktop Burners or Zones | 4 |
|---|---|
| Number of cooking zones | 4 |
Warranty
| Manufacturer Warranty | 5 years |
|---|---|
| Use | Not intended or designed for commercial use. |
Air Extraction
| Max Air Capacity | 595 m³/h |
|---|---|
| Number of fan speeds | 3 |
| Ducting size | Custom Design |
| Can be recirculated | |
| Ducting location | Rear |
Other Features
| Features | Installation: Choose a Flush installation for a seamless, integrated look, or a Proud installation for a bold, elevated design statement. OptiGlass Finish: OptiGlass is an extra hard glass finish that increases the bench’s resistance to scratches and keeps its surface in pristine condition for longer. ZoneFlex Technology: This cooktop can be used with both standard and oversized cookware and comes with various power levels and preset modes, for even more freedom and flexibility while cooking. OptiLink to Rangehood: OptiLink connects the cooktop to the rangehood, automatically adjusting ventilation settings based on cooking intensity for optimal air quality. Ergonomic Sliders: Electronic multi-slider controls ensure quick and easy control of the power level of each individual cooking zone. Sensor Controlled Cooking: The additional Simmer, Keep Warm and Melt functions available on most cooktops in this category use sensors to control the cooking process. Downdraft System: The integrated downdraft system efficiently extracts cooking fumes directly from cookware, ensuring a clean, odour-free kitchen environment. Power Levels: 9 Variable levels Extra Features: Warming, Pan Detection, Bridging Function, Pause, Cleaning Lock, Child Lock, Swiss Made: SwissMade and designed, all V-ZUG products are supported by a 10-year manufacturer's warranty. Cooktop Zone: |
|---|---|
| Automatic pan detection | |
| Control type | Touch controls |
| Motor Type | Brushless |
| Outdoor | |
| Portable | |
| Timer | |
| Cooling fan | |
| Boost function | |
| Clean filter indicator | |
| Flexible zones | |
| Integrated Ventilation | |
| Easy clean cooking surface | |
| Cooktop Configuration | 4 Burners |
Noise Level
| Lowest Operating Noise | 34 dB |
|---|---|
| Highest Operating Noise | 70 dB |
Electrical Connection
| Type of connection | Hardwired |
|---|---|
| Connected load | 7.4 kW |
| Connection requirements | Needs to be hardwired by a qualified electrician |
| Maximum current rating | 31 A |
Safety Features
| Child lock | |
|---|---|
| Residual heat indicator | |
| Spill protection |
Display
| Display |
|---|
Filters
| Filter material | Stainless Steel mesh |
|---|---|
| Number of filters | 1 |
| Dishwasher safe filters |
Country of Origin
| Origin | Switzerland |
|---|
Product Details
| Condition | New Condition |
|---|---|
| Description | Ex display.
Ducting is not included and ordered separately.
Needs to be hardwired. |
| Missing Parts | Installation clips (if not installed). |
| Price | 7085 |
Other
| Primary Product Category | Cooktops with Ventilation System |
|---|---|
| Built In | |
| Filter | Yes |
| EAN | 7630029457573 |
