Bosch 90cm Series 6 Stainless Steel Canopy Rangehood DWB97LM50A
DentScratch
Bosch 90cm Series 6 Stainless Steel Canopy Rangehood DWB97LM50A
Model
DWB97LM50A
Condition Description
Front under panel has scratches.
Both flues have dents and scratches.
Grease filters have minor dents.
Missing parts
User/Install manual.
Duct reducer.
One way valve duct..
Flue fixing bracket, 2 screws and washers.(A).
2 x Brackets and 2 x Screws (B)
5 x Wall plugs.
1 x Threaded bolt (C)..
1 x Knurl nut. (G).
2 x Flue screws.
Brand
Standard Warranty
2 Years
4 payments of $108.75 with
Own it from $10 per week with Zip Pay
Specifications & Manuals
Key Specifications
| Rangehood Type | Canopy |
|---|---|
| Model Number | DWB97LM50A |
| Weight (kg) | 18.8 kg |
| Depth (mm) | 500 mm |
| Height (mm) | 1064 mm |
| Width (mm) | 898 mm |
| Power (W) | 145 W |
| Accessories included | 2 x Stainless Steel Flue Covers. |
| Finish Colour | Stainless Steel |
| Notes | This model can be ducted externally using the optional extra ducting kits and Recirculation Kits are available Online to add to your order.
|
| Finish Colour Description | Stainless Steel Finish. |
| Rangehood Model Number | DWB97LM50A |
| Installation Note | Wall Mounted Installation |
Warranty
| Manufacturer Warranty | 2 Years |
|---|---|
| Warranty Note | 2 Year Domestic Warranty on all Parts & Labour. |
| Use | Not intended or designed for commercial use. |
Air Extraction
| Max Air Capacity | 697 m³/h |
|---|---|
| Number of fan speeds | 4 |
| Ducting size | 150 |
| Can be recirculated | |
| Ducting location | Top |
Other Features
| Features | The wall-mounted rangehood: a functional design element in the kitchen. ● Extraction rate: at 697 m3/h, it quickly ensures optimal kitchen air quality. ● Especially quiet: high performance at just 55 dB. ● LED lighting: for perfect, energy-efficient illumination of the cooktop. ● Intensive speed setting with reset: automatically resets the hood to regular speed setting after 6 min. Design & Innovation ● Box design ● Appliance colour: Stainless steel Power and Mode of Operation ● 3 power settings plus intensive setting ● Extraction rate according to EN 61591 ø 15 cm: max. Normal use 431 m3/h, Intensive 697 m3/h ● Extraction rate in recirculation mode: Max. normal use: 319 m3/h ● Ducted and recirculated-air operation ● Electronic controls with white LED display ● TouchControl ● EcoSilence BLDC brushless motor ● Noise min./max. Normal Level: 45/55 dB ● Noise max. Intensive setting: 66 dB ● Noise level in recirculation mode: Max. normal use: 70 dB(A) re 1 pW (57 dB(A) re 20 µPa sound pressure ● Energy Efficiency Class: A (at a range of energy efficiency classes from A++ to E) ● Average Energy Consumption: 33.1 kWh/year ● Power rating: 145 W Comfort & Convenience ● One-way flap: prevents outside air from entering your kitchen ● Dishwasher safe metal grease filters ● 3 x 1.5 Watt LED Lights ● Intensive operation automatic revert - 6min ● Additional sound insulation mats for optimised sound absorption Technical Information ● Appliance width: 898 mm ● Dimensions exhaust air (HxWxD): 628-954 x 898 x 500 mm ● Dimensions recirculating (HxWxD): 628-1064 x 898 x 500 mm ● Diameter pipe Ø 150 mm (Ø 120 mm enclosed) ● Electrical cable length 1.3 m |
|---|---|
| Programmable timer | |
| Control type | Touch controls |
| Light type | LED |
| Motor Type | Centrifugal |
| Boost function | |
| Clean filter indicator |
Electrical Connection
| Type of connection | 10A plug & lead |
|---|---|
| Connection requirements | This product requires a 10amp electrical connection. For more information, please contact Winning Services on 1300 020 020 or your electrician. |
| Maximum current rating | 10 A |
| Length of cord | 1.3 m |
Filters
| Filter material | Aluminum Mesh |
|---|---|
| Number of filters | 3 |
| Dishwasher safe filters |
Noise Level
| Noise when in operation - low to high | 45 - 66 |
|---|---|
| Noise when working | 55 dB |
Country of Origin
| Origin | Germany |
|---|
Product Details
| Condition | Cosmetic Imperfection |
|---|---|
| Description | Front under panel has scratches.
Both flues have dents and scratches.
Grease filters have minor dents. |
| Missing Parts | User/Install manual.
Duct reducer.
One way valve duct..
Flue fixing bracket, 2 screws and washers.(A).
2 x Brackets and 2 x Screws (B)
5 x Wall plugs.
1 x Threaded bolt (C)..
1 x Knurl nut. (G).
2 x Flue screws. |
| Price | 435 |
Other
| Primary Product Category | Rangehoods |
|---|---|
| Depth Package Dimensions | 970 mm |
| Dishwasher safe parts | |
| Filter | Yes |
| Height Package Dimensions | 585 mm |
| Width Package Dimensions | 650 mm |
| Packaged Weight | 24.6 kg |
| EAN | 4242005107728 |
Manuals & Downloads
